PAPER BAG MAKING MACHINE
PAPER BAG MAKING MACHINE
The machine is the latest design of our company's products.It can make paper bags with laminated film ,All the operation procedures are controlled by PLC .The machine has many advantages such as easy to operate,firm sealing ,perfect output. This machine is an ideal machine for producing air -sickness bags .Train sichness bags and various kinds of sickness bags .
Product Comments
CY-450 MID-sealing paper-poly pouch making machine can make paper bags with laminated film .
Main Technical Variables
Suitable material: PE Coated paper
Paper weight: 30-100GS/m2
Bag length: 70-600mm
Bag width: 70-450mm
Gusset width :0-60mm
Paper weight:30-100g
Film thickness:10-50micron
Air pressure:4MPA
Speed: 30-80PCS/min
Main motor: 2.2KW
Total weight: 2000KG
Machine dimension: 1200x6500x1600mm
1.Multi-functional digit-display infinite speed regulation,PLC control systems are adopted. 2.Touch screen is equipped, so man-machine interface is achieved. 3.Fully automatic feeder is adopted 4.The machine can be used to pack common and advanced printed sheets. 5....
This machine is designed to manufacture square bottom paper bags from paper roll in blank or printed. Side gluing, tube forming, cutting, bottom creasing, bottom gluing, bottom forming and final product out feed can be completed within one time by this machine. It is id...
Paper Bag Making machine can produce the square bottom paper bag in conjunction with overseas advanced technology. The machine has many advantages such as high speed,high productive efficiency and wide-rang adjustment. It is an ideal machine for producing Square Bott...
CY-400 Automatic High Speed Paper Food Bag Machine online with 2 color printing machine can make paper bags in one process from roll paper, edge folding, tube forming, cutting, gluing, bottom folding, bottom gluing and finishing bag. It is an ideal machine for produc...
